In order to ensure proper operation and efficiency of your Lifegard sterilizer all bulbs and quartz sleeves should be changed on a yearly basis.It is highly recommend when you change your quartz sleeve that you use silicon lubricant to ensure the sleeve is not damaged.The quartz sleeve fits the Lifegard ProMax 25W UV Sterilizer. Manufacturer Part Number: R450228A
Replacement Overflow Pipe for the Lifegard Aquatics 15W UV Sterilizer.This item should be replaced once every year to maintain optimal performance of you UV Sterilizer.It is also recommended to change the protective sleeve portion of the UV Sterilizer at the same time.
IceCap In-Sump UV Sterilizer - 27 Watt
OverviewThe 27 W In Sump model adds capacity and dwell time for mid sized aquariums while keeping the same drop in simplicity. It ships with the matched feed pump so you can achieve effective exposure without guesswork and enjoy clearer water and healthier livestock faster.Features
Plug and play in sump installation
Matched feed pump included for proper flow
High output UV lamp with reliable ballast
Reduces free floating algae bacteria parasites and fungi
Leaves beneficial biofilter bacteria on media and surfaces intact
Specifications
Item: IC-UVR-27INT
Freshwater up to: 1300 gal
Marine up to: 140 gal
Dimensions L x W x H: 4.6 x 4.3 x 22 in
UV Power: 27 W @ 120 V
Lamp length: 11.3 in
Current: 800 mA
UVC output: 75 uW/cm2
Lamp life: 10000 hours
Included pump: EVO 1000 15 W @ 120 V
Compatibility and Upgrade PathsWorks in most standard sump chambers; combine with mechanical filtration for best water polishing. If bioload increases consider the 40 W model or additional mechanical or chemical media to complement UV performance.Maintenance and CareClean the quartz sleeve on schedule and ensure adequate flow and water level. Replace the UV lamp at 10000 hours or annually for best performance and keep the pump free of debris and calcium buildup.Warranty and Service1 year limited warranty through CoralVue from date of purchase; service and claims handled via the CoralVue Support Portal.Shipping and Handling NotesShips as a glass and electronic assembly; handle carefully and keep dry during installation. Use a GFCI and drip loop for safety.DirectionsStand the unit upright in a sump chamber with constant water level attach and position the included EVO 1000 pump per the manual confirm unobstructed flow through the UV chamber then power on and monitor results over the next several days.What's Included
IceCap In Sump UV Sterilizer assembly with HO UV lamp
Feed pump EVO 1000
Power cord and ballast integrated
IceCap In-Sump UV Sterilizer - 18 Watt
OverviewThe IceCap In-Sump UV Sterilizer reduces free floating algae bacteria parasites and fungi to enhance clarity and fish health without chemicals. The drop in design sits directly in your sump and includes the correct feed pump for easy plug and play setup and consistent exposure time.Features
Super simple drop in sump installation
Plug and play with feed pump included
High output UV lamp and reliable ballast
Helps clarify water and reduce disease spread
No permanent plumbing and will not harm beneficial bacteria on surfaces and media
Specifications
Item: IC-UVR-18INT
Freshwater up to: 600 gal
Marine up to: 60 gal
Dimensions L x W x H: 3.5 x 3.5 x 18.4 in
UV Power: 18 W @ 120 V
Lamp length: 7.3 in
Current: 800 mA
UVC output: 50 uW/cm2
Lamp life: 10000 hours
Included pump: DC-700 8.5 W @ 12 V
Compatibility and Upgrade PathsIdeal for AIO and compact sump systems; pairs well with mechanical filtration to remove killed particulates. For larger systems consider the 27 W or 40 W In Sump models or IceCap inline UV options as your bioload grows.Maintenance and CareWipe the quartz sleeve per the manual to remove film check pump intake for debris and replace the UV lamp annually or at 10000 hours. Never run dry and maintain stable sump water level for consistent exposure time.Warranty and ServiceBacked by a 1 year limited warranty through CoralVue with support via the CoralVue Support Portal; warranty begins on purchase date and covers defects in materials and workmanship per CoralVue terms.Shipping and Handling NotesHandle as a delicate electronic and glass assembly; inspect on arrival and keep dry during transit and storage. Install on a GFCI protected circuit with a drip loop.DirectionsPlace the unit upright in a stable sump chamber with constant water level connect and position the included pump per the manual ensure unobstructed intake and outlet plug in the pump and ballast verify flow through the chamber and monitor clarity and livestock for improvements over the first weeks.What's Included
IceCap In Sump UV Sterilizer assembly with HO UV lamp
Feed pump DC-700
Power cord and ballast integrated
IceCap Controllable DC Media Reactor - Large
OverviewFor higher bioload or larger aquariums the IceCap Large DC Media Reactor delivers generous capacity and a controllable 12V DC pump to drive precise flow through GFO carbon or biopellets while the removable twin chamber canister makes service quick and clean.Features
Complete plug and play package with adjustable 12V DC feed pump
Twin chamber media canister promotes even contact and easy swaps
Robust acrylic construction for marine or freshwater systems
Small footprint relative to capacity for flexible sump placement
Suitable for phosphate control water polishing or carbon dosing via biopellets
Specifications
Item: IC-GFO-80P
L x W x H: 3.5 x 3.5 x 16.25 in
Body Size: 3.2 in
Max Media Capacity: ~820 mL
Pump: DC-700 (8.5 W @ 12 V)
Flow Range: ~210–700 L/h
Aquariums up to: 200 gal
Compatibility and Upgrade PathsUse with GFO activated carbon or biopellets. Integrates with CoralVue ecosystems including IceCap EXT or INT reactors and other filtration equipment as needs grow.Maintenance and CareRinse media dial in flow to achieve gentle tumble for GFO steady contact for carbon or active roll for biopellets and clean pump and screens routinely. Do not run dry and protect from salt creep and debris buildup.Warranty and Service1 year limited warranty provided by CoralVue beginning on purchase date; support available via CoralVue Support Portal.Shipping and Handling NotesAcrylic reactor and DC pump ship together; verify condition on arrival and rinse canister components before use.DirectionsLoad rinsed media into the canister seat the canister connect the included DC pump start low and increase power until the desired media movement is achieved then monitor parameters and adjust as needed.What's Included
IceCap Large DC Media Reactor with removable twin chamber canister
Controllable 12V DC feed pump with controller
IceCap Controllable DC Media Reactor - Small
OverviewCompact and plug and play the IceCap Small DC Media Reactor gives AIO and sump systems precise control over GFO activated carbon or biopellets using a twin chamber canister and a 12V controllable DC pump with five power modes for optimal media contact time.Features
Feed pump included adjustable 12V DC with five power modes
Removable twin chamber canister prevents channeling and makes swaps fast
Small footprint ideal for All In One aquariums and tight sump spaces
Durable acrylic construction for freshwater or marine use
Easy media changes without removing the entire reactor
Specifications
Item: IC-GFO-50P
L x W x H: 2.2 x 2.2 x 12 in
Body Size: 2 in
Max Media Capacity: ~170 mL
Pump: DC-200 (5 W @ 12 V)
Flow Range: ~60–200 L/h
Aquariums up to: 40 gal
Compatibility and Upgrade PathsWorks with GFO activated carbon and biopellets; pair with fine or coarse media as needed. Scales with larger IceCap DC Media Reactors or EXT/INT reactors if your system grows and integrates well alongside filter rollers or socks.Maintenance and CareRinse new media thoroughly; for GFO aim for a gentle tumble for carbon use slow even flow and for biopellets maintain active rolling. Clean the pump and sponge screens regularly and never run the reactor dry.Warranty and Service1 year limited warranty from CoralVue covering defects in materials and workmanship; support via the CoralVue Support Portal.Shipping and Handling NotesShips as an acrylic reactor with DC pump; handle carefully and avoid impacts. Rinse canister sponges and media basket parts before first use.DirectionsLoad rinsed media into the twin chamber canister seat the canister connect the included DC pump set initial power to a low setting and adjust until media moves appropriately then monitor effluent clarity and nutrients and fine tune as needed.What's Included
IceCap Small DC Media Reactor with removable twin chamber canister
Controllable 12V DC feed pump with controller
IceCap UV Sterilizer Bulb - 40 Watt
Overview
Replacement bulb for the IceCap 40W UV sterilizer for aquariums and ponds.
Manufacturer Part Number: IC-UV-40B
In order to ensure proper operation and efficiency of your Lifegard sterilizer all bulbs and quartz sleeves should be changed on a yearly basis.It is highly recommend when you change your bulb that you use the silicon lubricant to ensure the bulb is not damaged.
