Eshopps Prodigy External Overflow - Medium

Eshopps Prodigy Medium Ultra-Slim Overflow

The Eshopps Prodigy External Overflow - Medium provides efficient surface skimming and sump drainage while occupying only 5/8 inch of space inside the aquarium. Its exceptionally slim internal weir preserves valuable swimming and aquascaping room while the clear external overflow box keeps the drain plumbing outside the display.

Designed for aquariums from 20 to 70 gallons with flow rates up to 700 GPH, the Prodigy Medium includes an adjustable water-height weir, recessed external cover and separate primary and safety drain connections. The included template and diamond hole saw provide the core components required to install the overflow on a suitable aquarium panel.

Prodigy Medium Low-Profile Features

• Ultra-slim 5/8-inch internal profile preserves display space
• Adjustable surface-skimming weir controls the aquarium operating-water height
• Clear external overflow box makes the internal water level easy to inspect
• Recessed external lid helps contain splash and reduce operating noise
• Two 1-inch drain bulkheads support primary and safety drain plumbing
• Red PVC safety standpipe provides a clearly identifiable backup drain
• Included template and diamond hole saw simplify accurate positioning
• Suitable for aquarium panels up to 5/8 inch thick

Eshopps Prodigy Medium Specifications

• Eshopps item number: 95857
• Internal box dimensions: 8 x 5/8 x 6 inches
• Internal metric dimensions: 203 x 16 x 153 mm
• External box dimensions: 8 x 3 x 6 inches
• External metric dimensions: 203 x 76 x 153 mm
• Recommended aquarium size: 20 to 70 gallons
• Maximum flow rate: 700 GPH
• Metric maximum flow: 2,650 LPH
• Maximum aquarium-panel thickness: 5/8 inch
• Transfer bulkhead: One 1.5-inch bulkhead
• Drain bulkheads: Two 1-inch bulkheads

See the Eshopps Prodigy Overflow in Action

Prodigy Medium Installation and Plumbing Notes

The Prodigy Medium requires drilling one transfer opening through the aquarium panel. Confirm that the selected glass panel is non-tempered and suitable for drilling before beginning. Tempered aquarium glass must not be drilled.

The overflow should be positioned according to the desired operating-water level while leaving sufficient clearance behind the aquarium for the external box, cover and drain plumbing. The connected return pump should remain within the 700 GPH maximum flow rating after head-pressure loss.

The two 1-inch drains can be arranged as a controlled primary drain and an unrestricted safety drain. Always test the system with the primary drain restricted to confirm that the backup drain can safely manage the aquarium flow.

Eshopps Prodigy Medium Installation Directions

Use the supplied template to establish the overflow position and confirm that the internal and external boxes will clear the aquarium trim, stand and surrounding equipment. Follow the complete Eshopps installation instructions when drilling the suitable aquarium panel.

Install the transfer bulkhead and gaskets with the internal weir and external box properly aligned. Fit the two 1-inch drain bulkheads, install the red safety standpipe and connect the required drain plumbing. Adjust the internal weir to establish the desired display-water height.

Test the completed system with fresh water before normal aquarium operation. Confirm leak-free connections, safe return-pump shutdown and sufficient backup-drain capacity before leaving the overflow unattended.

What's Included

• Black internal overflow box with adjustable weir
• Clear acrylic external overflow box
• Recessed clear external-box lid
• One 1.5-inch transfer bulkhead
• Two 1-inch drain bulkheads
• Bulkhead gaskets
• Red PVC safety standpipe
• Diamond-coated glass hole saw
• Drilling template
• Installation instructions and warranty information
